Mechanically cooks, dries, and sheers oilseeds to maximize mechanical extraction of oil.

The Dox (Dry Oilseed EXtruder) is designed to mechanically shear, cook, and dry the material being processed for improved oil recovery. The high-shear environment ruptures the oil-containing bodies within the oilseed and generates frictional heat. This heat deactivates harmful enzymes within the oilseed, flash-dries excess moisture, and cooks the proteins for a more efficient pressing.

This pretreatment system achieves the lowest possible extraction of oil levels in your meal.


Installing a Dox ahead of an Expeller® doubles the capacity of the press, replaces expensive steam-heated cooking vessels, doubles the life of the pressing parts, and reduces meal oil residuals to under 6%. The oilseeds processed with this extruder are low-oil content seeds (less than 25% oil).

The extruder aids in breaking down material for the most efficient oil recovery possible. The heat treatment deactivates the trypsin inhibitor and urease enzymes which reduce the value of the meal if not properly destroyed. With the extrusion pretreatment, the processors will be able to achieve the lowest possible extraction of oil levels in your meal of 5-6%.

Related Blogs


Features and Applications


Features

  • High Shear Discharge Head
  • Optional Drainage Cage
  • V-Belt or Gear Drive
  • Manually or Hydraulically Operated Choke
  • VFD Driven Feeder
  • Shear Pins

Applications

  • Soybean (non-GMO, organic, and high oleic)
  • Whole Cottonseed
  • Pre-press Cake

Anderson Dox Hivex Oil HatchDox-Hivex™ Extruder

The Dox-Hivex™ Extruder incorporates a drainage cage to allow for the extrusion of high oil content materials (over 30%) while recovering over 50% of the available oil.

Applications

  • Canola/Rapeseed
  • Sunflower
  • Cottonseed meats
  • Peanuts/Ground Nuts
  • Palm Kernel
  • Copra

Anderson Dox Extruder

Anderson-Dox-New
RATED PERFORMANCE BY MODEL
ModelConnected HPCapacity (MTPD)
Dox 800 & 800H150-20040-60
Dox 1200 & 1200H300-400100-160
